GFP 363TH 63" Wide Format Cold Laminator with Top-Heat
- 0
- 1
- 2
- 3
- 4
- 5
Overview
Specifications
Item # | 04GFP363TH |
---|---|
Manufacturer | GFP Graphic Finishing Partners |
Manufacturer Item # | 363-TH |
Laminator Type | Cold Laminator / Pressure Sensitive (with Top-Heat Assist) |
Format | Wide Format Laminating |
Laminating Width | 63 Inches |
Maximum Speed | 20 Feet per Minute (fpm) |
Main Rollers | Rubber (4.5" Diameter) |
Roller Gap | 1 Inch |
Pressure/Gap Adjustment | Infinite (Hand Wheel) |
Maximum Roll Diameter | 4.5 Inch Outside Diameter |
Heat Method | Metal Alloy Heater |
Top-Heat Assist | Yes |
Maximum Temperature | 122° F |
Rear Rewind | Integrated |
Liner Rewind | Chain Drive |
Tension Adjustment | Single Knob |
Power Supply/Consumption | 120v 11A 1300W |
Included Accessories | Foot Pedal, Stand with Caster Wheels |
Optional Accessories | 363COV Dust Cover |
Applications | Signs, Posters, POP Displays, Trade show displays, Single side lamination, Graphic mounting, Photo mounting, Floor graphics, Vinyl Weeding, Colored Vinyl, Pre-mask |
Manufacturer's Warranty | 1 Year Limited Parts & Labor |
Machine Dimensions | 80 Inches x 23 Inches x 48 Inches |
Net Weight | 370 lbs. (with included stand) |
Shipping Dimensions | 87 Inches x 26 Inches x 31 Inches |
Shipping Weight | 507 lbs. |
Shipping Method | Truck |
Description
The GFP 363TH 63" Top Heat Wide Format Roll Laminator adds top heat for better overlamination, mounting, and board pre-coating. It is an affordable option for pressure-sensitive applications. It has a rugged construction, labor-saving features, and high quality output in an entry level machine. The GFP 363TH has a laminating width of up to 63" with a speed of up to 20 feet per minute. Other great features include: Integrated Rear Rewind for easy Roll-to-Roll applications, Media Alignment Disks that prevent media supply roll from telescoping during operation, and Photoelectric eye for operator safety. This GFP 363TH 63" Top Heat Wide Format Roll Laminator is backed by a 1-year manufacturer's warranty on parts and labor.
Key Features:
- Adds top heat for better over-lamination, mounting, and board pre-coating
- Easy set-up and low maintenance with a top heat boost
- Labor-saving 3" Aluminum Quick-Grip film shafts
- Integrated rear rewind for roll-to-roll apps
- Swing-up feed table and 38" output height
- Photoelectric eye for operator safety
- Metal Alloy heater reduces breakage
- 5" diameter rollers
- Media Alignment Disks prevent media supply roll from telescoping during operation
- Stand, Foot Switch, and Rewind included
Popular Applications:
- Signs
- Posters
- POP Displays
- Trade show displays
- Dry erase boards
- Single side lamination
- Graphic mounting
- Photo mounting
- Floor graphics
- Vehicle graphics
- Window graphics
- & More
