Formax FD 6104 Low-Volume Automatic Mail Folder & Inserter
7350 NewCondition InStock

Formax FD 6104 Low-Volume Automatic Mail Folder & Inserter

Item #: 04FD6104
Brand: Formax
FAQ: 1 Questions, 1 Answers
  • Ideal for Lower Volume Mail Rooms & Offices
  • Color Touchscreen for Easy Operation
  • 15 Programmable Jobs for Quick Recall
  • Compatible with #10 and 6" x 9.5" Envelopes
Please Note: Call (866) 537-2244 for Quote on Required Install & Training
  • 90 Day Manufacturer Warranty
  • 85+ Years Experience
  • Oversize / Truck shipping
  • Brand New

$7,350.00

Buy Now, Pay Later
Starting at $680/monthLearn More >

SWIPE FOR MORE IMAGES
  • 0
  • 1
  • 2
  • 3
  • 4
  • 5
  • 6
video

Overview

With the Formax FD 6104 automatic mail folder and inserter, you can bring new efficiency to your low-volume mail room or shipping area. This system offers the latest technology for entry-level tabletop inserting machines, making it possible for any business to enjoy the benefits of an automated system. It has an easy-to-navigate 5" color touchscreen with a wizard-based software that guides your operators through the setup and operation from start to finish. The FD 6104 offers fast access to up to 15 saved/programmable jobs from the home screen, and bold icons indicate to the operator the current functional status of the feeders.

With two fully-automatic sheet feeders and one automatic insert/BRE feeder, it offers a range of folding and inserting capabilities. It processes documents up to 14" long, producing up to 1,350 envelopes per hour. Electromagnetic double document detection ensures each envelope contains the correct number of documents.

The output envelope catch tray comes standard with the FD6104. An optional Fold-only C-Fold Kit is available for those who need to produce C-folded documents without inserting into an envelope, ideal for brochures and marketing pieces. The kit is easily installed without tools, simply by swapping out the moistener kit.

Specifications

Item # 04FD6104
Manufacturer Formax
Manufacturer Item # FD 6104
Fixed Speed Up to 1,350 Pieces / Hour
Duty Cycle Up to 5,000 Pieces / Month
Paper Size Up to 8.5" x 14"
Programmable Jobs Up to 15
Compatible Envelopes #10 & 6 x 9.5"
Folding Capacity Up to 5 Sheets at Once (Depending on Stock)
Fold-Only Mode Yes
Control Panel 5" Full-Color Touch Screen Controls
Dedicated BRE/Insert Feeder Yes, Fold and/or Insert Sheets and BREs
Resettable Counter Yes
Eco Mode Energy-Saving Sleep Mode After 1 Hour of Inactivity
Double Document Detection Electromechanical Sensors
Adjustable Catch Tray Yes; Holds up to 100 Envelopes
Seal and Non-Seal Capabilities Yes
Cascade Mode Yes
Saily Seal Mode Yes
Paper Size 5.6" - 8.9"’ W x 7" - 14" H
Paper Weight 18 - 30 lbs (68 - 113gsm)
Insert/BRE Size 5.6" - 8.9" W x 3.5" - 5.9" H
Insert Weight 20 - 62 lbs (75 - 233gsm)
BRE Weight 19 - 30 lbs (71 - 113gsm)
Outgoing Envelope Size 8.8" - 9.5" W x 4.1" - 6" H
Dimensions w/o Catch Tray 26" L x 17" W x 22" H
Weight 82 lbs
Voltage 120 Volts AC 50/60Hz
Safety Certifications UL approved

Description

The FD 6104 inserter offers the latest technology in entry-level tabletop inserters, making it possible for any size company to enjoy the benefits of automated folding and inserting. The affordability of this inserter eliminates the need to send out tens of thousands of mail pieces in order to justify the cost of automation.



The 5” full-color touchscreen control panel features wizard-based software which guides operators through setup and operation. It provides quick access to saved jobs, right on the home screen, while bold icons indicate the status of each feeder. Users can program up to 15 jobs for instant, one-touch operation.



With two fully-automatic sheet feeders and one automatic insert/BRE feeder, it offers a range of folding and inserting capabilities. It processes documents up to 14” in length, producing up to 1,350 envelopes per hour. Electromagnetic double document detection ensures each envelope contains the correct number of documents. The energy-saving mode automatically puts the inserter into standby after one hour of being idle.



The output envelope catch tray comes standard with the FD6104. An optional Fold-only C-Fold Kit is available for those who need to produce C-folded documents without inserting into an envelope, ideal for brochures and marketing pieces. The kit is easily installed without tools, simply by swapping out the moistener kit.



The FD 6104has the ablity to operate in Daily Mail Mode to for inserting stapled sets. It has both seal and non-seal capabilities. When set in Cascade Mode operation, the unit will maximizes output by connecting feeders with the same document. When the first feeder empties, the second automatically starts feeding, for a total hopper capacity of up to 200 sheets.



Don’t waste any more valuable time and money manually folding and inserting.  Automate your mailings with the FD 6104 and maximize your company’s efficiency.



Key Features:

  • 5” Color Touchscreen: Graphical interface provides quick, easy setup, with job list on the home screen
  • Versatile: 2 1/2 stations insert 1-2 sheets plus BREs/small inserts
  • Speed: Produces up to 1,350 filled envelopes per hour
  • 15 Programmable Jobs: Handy for recurring or frequently processed applications
  • Dedicated BRE/Insert Feeder: Fold and/or insert sheets and BREs
  • Clamshell Design: Easy access to the paper path
  • Easy Load Feeders: Top-loading, with adjustable side guides
  • Accumulate Before Folding: Documents are folded and inserted together
  • Double Document Detection: Electromechanical sensors are unaffected by dust, smudges or paper color, providing essential document integrity
  • Fold Types: C, V, Double Parallel, no fold
  • Fold Only without Inserting
  • Folding Capacity: Up to 5 sheets
  • Resettable Counter: Provides accurate count of envelopes processed
  • ECO Mode: Energy-saving feature places the inserter into sleep mode after 1 hour of inactivity
  • Catch Tray (Comes Standard with FD6104): Adjusts to hold up to 100 envelopes, #10 and 6” x 9.5”



Abilities:

  • Daily Mail Mode: For inserting stapled sets
  • Seal and Non-Seal Capabilities
  • Cascade Mode: Maximizes output by connecting feeders with the same document. When the first feeder empties, the second automatically starts feeding, for a total hopper capacity of up to 200 sheets.



Optional Accessories (Sold Separately):

  • Fold-only C-Fold Kit: Creates C-folded sheets that don’t require inserting, ideal for brochures, marketing pieces, fundraising, and more. Easily installed by temporarily replacing the moistener kit.

Videos

FD 6104 Overview & Setup Instructions

Transcript: The FD 6104 inserter offers the latest technology in entry-level tabletop inserters, making it possible for any size company to enjoy the benefits of automated folding and inserting. The affordability of this inserter eliminates the need to send out tens of thousands of mail pieces in order to justify the cost of automation.

The 5” full-color touchscreen control panel features wizard-based software that guides operators through setup and operation. It provides quick access to saved jobs, r...
Read More
The FD 6104 inserter offers the latest technology in entry-level tabletop inserters, making it possible for any size company to enjoy the benefits of automated folding and inserting. The affordability of this inserter eliminates the need to send out tens of thousands of mail pieces in order to justify the cost of automation.

The 5” full-color touchscreen control panel features wizard-based software that guides operators through setup and operation. It provides quick access to saved jobs, right on the home screen, while bold icons indicate the status of each feeder. Users can program up to 15 jobs for instant, one-touch operation.

With two fully-automatic sheet feeders and one automatic insert/BRE feeder, it offers a range of folding and inserting capabilities. It processes documents up to 14” in length, producing up to 1,350 envelopes per hour. Electromagnetic double document detection ensures each envelope contains the correct number of documents. The energy-saving mode automatically puts the inserter into standby after one hour of being idle.

A Tri-Fold Kit is available for those who need to produce even-panel C-folded documents, ideal for brochures and marketing pieces that don’t require an envelope. The kit is easily installed without tools, simply by swapping out the moistener kit.

Don’t waste any more valuable time and money manually folding and inserting. Automate your mailings with the FD 6104 and maximize your company’s efficiency.

Product Reviews

Write Your Own Review
You're reviewing:Formax FD 6104 Low-Volume Automatic Mail Folder & Inserter
Your Rating

Frequent Asked Questions

Q
Does The Formax FD 6104 come with the envelope catcher attached or to be purchased seperately
Asked by Tiffany Green
A
Great question! The output envelope catch tray comes standard with the FD6104. There is no additional cost and this item is very easy to put in place.
Answer by Binding101
