Drytac Dry Mount Film Clear Heat-Activiated Acrylic Mounting Adhesive
- Film Length: 82' - 328'
- Film Width: 41" - 51"
- Film Width: 41" - 51"
- Release Liner: 1 Side PE Coated Bleached Kraft Grey Grid Paper (Moisture Stable)
- Free Shipping $75+
$379.88
- 0
- 1
- 2
Overview
The Drytac Dry Mount Film Mounting Tissue is a thin PVC carrier coated on both sides with an acrylic heat-activated adhesive to affix irregular surfaces. Each side of the film is protected with a high-quality, moisture-resistant paper release liner. The release paper is removed when the film is ready to be used, revealing a low initial tack adhesive that enables the print to be positioned without the use of a tacking iron. Before it is inserted into a heated press, the print can be repositioned at any time. This dry mount film is ideal for mounting onto canvas, rough or smooth substrates, and most other irregular surfaces that are similar to those of metals.
Specifications
| Item # | DDMFMT |
|---|---|
| Manufacturer | Drytac |
| Brand | Drytac |
| Film Length | 82' - 328' |
| Film Width | 41" - 51" |
| Film Thickness | 50µ (2 mil) |
| Release Liner | 1 Side PE Coated Bleached Kraft Grey Grid Paper (Moisture Stable) |
| Adhesive | Solvent Acrylic (Heat Activated) |
| Carrier | Clear PVC |
| Adhesive Layer | 25µ (1 mil) on each side |
| Ratio Film / Adhesive | 1:1 |
| Heat Resistance Range | 70°C - 95°C (158°F - 203°F) |
| Adhesive Type | Acrylic |
| Adhesive Bond | Permanent |
| Initial Tack | Low |
| Processing Temperature | 185°F-212°F (85°C-100°C) |
| Dwell Time | 60-90 seconds |
| Application | Fine Art Prints, Picture Framing/Photography, Plaque Mounting |
Description
The Drytac Dry Mount Film Mounting Tissue is a thin PVC carrier coated on both sides with an acrylic heat-activated adhesive to affix irregular surfaces. Each side of the film is protected with a high-quality, moisture-resistant paper release liner. The release paper is removed when the film is ready to be used, revealing a low initial tack adhesive that enables the print to be positioned without the use of a tacking iron. Before it is inserted into a heated press, the print can be repositioned at any time. This dry mount film is ideal for mounting onto canvas, rough or smooth substrates, and most other irregular surfaces that are similar to those of metals.
Product Reviews
Technical Data
Typical Applications
- Suitable for mounting to canvas, heavily grained or textured substrates and irregular surfaces, such as most metals.
Product Structure
| Release Liner | 1 Side PE Coated Bleached Kraft Grid Paper (Moisture Stable) |
|---|---|
| Adhesive | Solvent Acrylic (Heat Activated) |
| Film | Clear PVC |
Physical Characteristics
| Film Thickness | 2 mil (50µ) |
|---|---|
| Adhesive Layer | 1 mil (25µ) on each side |
| Film/Adhesive Ratio | 1:2:1 |
| UV Protection Factor | Not Applicable |
| Outdoor Durability | Not Applicable |
| Service Temperature Range | -4°F to 203°F (-20°C to 95°C) |
| Peel Strength (20 min, FTM1) | 18 N/25mm |
| Shelf Life | Use within 1 year after opening original box |
| Storage Conditions | 59°F to 72°F (15°C to 22°C); 50 - 55% Relative Humidity |
Process Settings
| Equipment Type | Temperature | Dwell Time |
|---|---|---|
| Roller Laminator | Not recommended | |
| Press | 185°F to 210°F (85°C to 99°C) | 60 - 90 seconds |
