Formax FD6608 Series Mid-Volume Inserters / Folders

Brand: Formax
  • Full-Color Touchscreen: 10” touchscreen display features graphic icons for simple, intuitive use
  • Modular Flexibility: Configurations are available with up to 7 fully-automatic feed stations
  • AutoSet: Load envelopes and documents and the 6608 Series will adjust all settings automatically
  • Paper & Envelope Presence Sensors: Control panel displays which feeders need to be refilled
Please Note: Call (866) 537-2244 for Quote on Required Install & Training
  • Oversize / Truck shipping
Starting At:

$44,695.00

Choose Below
SWIPE FOR MORE IMAGES
  • 0
  • 1
  • 2
  • 3
  • 4
  • 5
video

Overview

The Formax FD6608 Modular Inserter Series adapts to most any folding and inserting application. Models are available with 2 to 7 stations, offering the flexibility to meet your specific needs. Various input configurations include a high-capacity document feeder for up to 725 sheets, 1 or 2 high-capacity production feeders, standard and special feeders, short feed trays and a thin booklet feeder.

Specifications

Item # 04FD6608S1
Manufacturer Formax
Manufacturer Part Number 04FD6608S1
Feeder Capacity Up to 325 sheets, 20# paper (each feeder) / 725 (Production Feeder)
Envelope Hopper Capacity Up to 500 envelopes, top-loading
Vertical Output Stacker Up to 500 filled envelopes, reverse stacking output
Side Exit Tray (optional) Up to 500 filled envelopes
Speed Up to 4,300 pieces per hour, #10 envelopes
Duty Cycle Up to 80,000 pieces per month
Programmable Jobs Up to 50
Paper Size* 3.5” - 14” L x 5.1” - 9” W
Envelope Size* 6.3” - 9.7” L x 3.5” - 6.3” W
Dimensions 60” L x 31” H x 18” D (four-station models)
Dimensions with Thin Booklet Feeder 79” L x 31” H x 18” D (four-station models)
Optional Accessories Complete line of accessories
Weight Approx. 242 lbs (four-station)
Voltage 100 Volts AC 50/60Hz
Safety Certifications UL, CE approved

Description

The Formax FD6608 Modular Inserter Series adapts to most any folding and inserting application. Models are available with 2 to 7 stations, offering the flexibility to meet your specific needs. Various input configurations include a high-capacity document feeder for up to 725 sheets, 1 or 2 high-capacity production feeders, standard and special feeders, short feed trays and a thin booklet feeder.

Standard features on the FD6608 include a 10" color touchscreen control panel with graphical interface, automatic paper and envelope presence sensors with indicators on the control panel, a vertical output stacker for up to 500 filled envelopes, and a top-loading envelope hopper with a capacity of up to 500 envelopes. AutoSet allows operators to load envelopes and documents, then adjusts all settings automatically with the ability to store up to 50 programmed jobs for instant recall. Its powerful folding capacity allows for folding up to 10 sheets (half fold) or up to 8 sheets (tri-fold) at one time, plus it's capable of folding and inserting top, middle and bottom-address documents into top-flap envelopes.**

Cascade Mode allows users to link feeders for continuous operation: when one feeder empties, another takes over. To ensure document integrity, double document detectors are located at both the feeder and insertion area to ensure the right documents get into the right envelopes. The FD6608 Series utilizes electromechanical detectors which can operate with any print density, paper color, thickness or paper dust. Documents requiring inspection can be delivered automatically to the divert station without interruption.

The 6608 Series also offers energy savings with its auto standby mode, which goes into effect after one hour of inactivity. Various levels of Barcode Recognition (BCR) and Optical Mark Recognition (OMR) are available and feature CIS scanning technology, which can scan codes printed in any location on a document. Optical Character Recognition (OCR) is also available, which uses page numbering in 1/1 or N-of-M format to ensure each set is complete before being inserted into an envelope.
Additional options include a thin booklet feeder for inserts up to 2.5mm thick, side exit tray, locking cabinet.

Features:

  • Full-Color Touchscreen: 10" touchscreen display features graphic icons for simple, intuitive use
  • Modular Flexibility: Configurations are available with up to 7 fully-automatic feed stations
  • AutoSet: Load envelopes and documents and the 6608 Series will adjust all settings automatically
  • Paper & Envelope Presence Sensors: Control panel displays which feeders need to be refilled
  • Mid-Volume Processing Speed: Processes up to 4,300 envelopes per hour
  • 50 Programmable Jobs: Program frequently used jobs for quick and easy operation
  • High-Capacity Vertical Output Stacker: Holds up to 500 finished envelopes with reverse stacking output, maintaining printing order
  • Large, Top-Loading Envelope Hopper: Holds up to 500 envelopes with on-the-fly reloading for continuous operation
  • Handles a Variety of Envelope Sizes: Inserts into envelopes up to 6.3" H x 9.7" W
  • Variety of Fold Types: C, Half, Z, Double Parallel and no fold
  • Daily Mail Mode: Easily inserts stapled sets
  • Multi-Feeding: Allows for a set number of pieces to be pulled from one feeder, then collated and inserted automatically
  • Cascade Mode: Feeders can be linked for continuous operation, when one feeder runs empty, another takes over, allowing operators to refill as needed until the job is complete
  • Rugged Folding Capability: Folds up to 10 sheets (half fold) or up to 8 sheets (tri-fold) at once
  • Versatile: Folds and/or inserts sheets, BREs and cards automatically
  • Insert Capability: Folds/inserts top, middle and bottom address documents into top-flap envelopes
  • Eco Mode: Saves energy by automatically switching into standby mode after one hour of inactivity

Document Security Features:

  • Double Document Detection: Electromechanical detectors located at each feeder and the insertion area operate with any print density, paper color or thickness, to provide exceptional security
  • Divert Station: Sensors redirect double documents and incomplete sets without interruption

Available Options:

  • CIS Scanner: Reads OMR 1-track, OCR, 1D Barcodes and 2D Data Matrix codes, printed horizontally or vertically anywhere on the page
  • Thin Booklet Feeder: Dedicated feeder inserts BREs or booklets up to 2.5mm thick
  • Production Feeders: 1 or 2, each feeds up to 1,200 sheets or 325 BREs
  • Side Exit Tray: Holds up to 500 filled envelopes
  • OMR, BCR and OCR: Optical Mark, Barcode and Optical Character Recognition for added security
  • Short Feed Trays: Designed for small inserts and BREs
  • Custom Cabinets: Enclosed cabinets on casters with a key lock for secure storage

* Note: Paper & envelope specifications may vary. All media must be tested.
** Note: Bottom-address documents can be processed only in Half and Z-fold modes, up to 5 sheets.

Videos

Formax FD 6608 Series Inserters Demo Video

Transcript: Formax presents the 6608 Series Inserters. The Formax 6608 series are powerful, easy-to-use, and energy-efficient inserters ideal for meeting growing mailing needs. These inserters can process up to 80,000 mail pieces per month at speeds of up to 40,300 per hour, saving both time and money. The 10-inch full-color touchscreen and step-by-step job wizard make setup and operation easier than ever before. The screen is adjustable forward and back for the best viewing angle and to enable operation fr... Read More

Formax presents the 6608 Series Inserters. The Formax 6608 series are powerful, easy-to-use, and energy-efficient inserters ideal for meeting growing mailing needs. These inserters can process up to 80,000 mail pieces per month at speeds of up to 40,300 per hour, saving both time and money. The 10-inch full-color touchscreen and step-by-step job wizard make setup and operation easier than ever before. The screen is adjustable forward and back for the best viewing angle and to enable operation from either side of the machine. The 6608 series is ideal for the office or mail room environment with its versatility and quiet operation.

Ten different models are available in two- to six-station configurations to meet a variety of mailing demands. Here are four of the ten models available:

The FT 6608 Standard with 2 standard sheet feeders.
The FD 6608 Standard 3F with one high-capacity feeder and 2 standard feeders.
The FT 6608 Special 5F with one high-capacity feeder, 2 special feeders, and 2 standard feeders.
The FD 6608 Special 6 with two special feeders and four standard feeders.
Each model features a divert station for documents which require additional handling.

To operate the 60608 series, begin by loading each of the feeders. Each standard size feeder, shown here, holds up to 325 sheets. The high-capacity feeder holds up to 725 sheets. All the feeders can be linked for a total capacity of up to 1,300 sheets in the four-station configuration shown. The 6608 features auto-detect paper and envelope sensors. The control panel displays each tray that is loaded. With the feeders loaded, press the automatic or manual button to set up your mailing.If automatic is selected, the 6608 will detect the document and envelope sizes and will automatically fold and insert the mail pieces based on that information. To engage the automatic setup, press the """"1x"""" button for a test piece. Check the piece to make sure it is folded correctly. If the documents are accurately folded and inserted, press the """"Mail OK"""" button, then press the start button to begin folding and inserting.
