Formax FD 6308 Series Fully Automatic Folder/Inserter
28474.67
35301.33
8
Formax FD 6308 Series Fully Automatic Folder/Inserter
Brand:
Formax
Please Note: Call (866) 537-2244 for Quote on Required Install & Training
- Free Shipping $150+
Starting At:
$28,474.67
Choose Below
SWIPE FOR MORE IMAGES
- 0
- 1
- 2
- 3
- 4
Overview
The Formax FD 6308 Series Fully Automatic Folder/Inserter saves you time and money. Its user-friendly features include a 7" colour touchscreen control panel with graphics-based display and automatic paper and envelope presence sensors, a vertical output stacker that holds up to 500 filled envelopes, and a standard feeder that can be refilled on-the-fly with a capacity of up to 325 envelopes. AutoSet allows operators to load envelopes and documents before automatically adjusting all settings and storing up to 50 programmed jobs for instant recall. It can handle documents of various lengths and thicknesses at speeds of up to 3,800 pieces per hour and 40,000 pieces per month. An optional CIS Scanner reads OMR, 1D and 2D Barcodes, QR codes, and OCR printed anywhere on the page, allowing multiple-page documents to be automatically inserted, eliminating the time-consuming task of manually collating and inserting.
Specifications
| Item# | FD 6308-GRP |
|---|---|
| Manufacturer | Formax |
| Manufacturer Item# | 04FD6308ST3 04FD6308SP3 04FD6308ST2F 04FD6308SP2F 04FD6308ST3I 04FD6308SP3I 04FD6308ST2FI 04FD6308SP2FI 04FD630800 04FD630802 04FD630805 04FD630810 04FD630820 04FD630850 04FD630860 04FD630870 04FD630885 04D200020 |
| Speed | Up to 3,800 pieces per hour |
| Duty Cycle | Up to 40,000 pieces per month |
| Standard Feeders | Up to 325 sheets each, 20# bond |
| High-Capacity Feeder (Standard 2F, Special 2F, Standard 2FP models) | Up to 725 sheets, 20# bond |
| Envelope Hopper | Up to 325 envelopes, top-loading |
| High-Capacity Vertical Stacker | Up to 500 filled envelopes |
| Sheet Size | 3.5” - 14” H x 5” - 9” W |
| Programmable Jobs | 50 |
| Maximum Insert Thickness | 1mm |
| Maximum Set Thickness | 2.5mm |
| Envelope Size | 3.5” - 6.4” H x 5.5” - 9.8” W (Paper & envelope specifications may vary. All media must be tested.) |
| Set Thickness | Up to 2.5 mm |
| Dimensions | 51” L x 29” H x 20” W |
| Weight | 175 lbs. (3 stations) |
| Voltage | 120V AC, 60 Hz |
Description
The Formax FD 6308 Series Fully Automatic Folder/Inserter saves you time and money. Its user-friendly features include a 7" colour touchscreen control panel with graphics-based display and automatic paper and envelope presence sensors, a vertical output stacker that holds up to 500 filled envelopes, and a standard feeder that can be refilled on-the-fly with a capacity of up to 325 envelopes. AutoSet allows operators to load envelopes and documents before automatically adjusting all settings and storing up to 50 programmed jobs for instant recall. It can handle documents of various lengths and thicknesses at speeds of up to 3,800 pieces per hour and 40,000 pieces per month. An optional CIS Scanner reads OMR, 1D and 2D Barcodes, QR codes, and OCR printed anywhere on the page, allowing multiple-page documents to be automatically inserted, eliminating the time-consuming task of manually collating and inserting.
Standard Features:
- 4 Standard Models Available: Configurations are available with or without intelligence
- 7” Color Touchscreen Control Panel: Graphical interface provides quick, easy setup
- 50 Programmable Jobs: Handy for recurring or frequently processed applications
- High-Capacity Vertical Stacker: Holds up to 500 finished envelopes in a neat, sequential stack
- Fully Automatic Adjustments
- Envelope & Paper Presence Sensors: Graphic indicators appear on the touchscreen control panel
- AutoSet: Automatically senses and sets paper length, fold type, envelope size, fold length and double document detection.
- Clamshell Design: Easy access to the paper path
- Visible Insert Area: Window allows users to see the insert area without stopping or opening the inserter
- Accumulate Before Folding: Documents are folded and inserted together
- Electromechanical Double Document Detection: Most reliable method, unaffected by paper color
- Locking Envelope Side Guides: Envelope infeed has a lockable thumbwheel to ensure accurate feeding
- Eco Mode: Energy-saving feature places the inserter into sleep mode after 1 hour of inactivity
Abilities:
- Multiple Insert Capability: Fold and/or insert sheets, BREs and cards in almost any combination
- Multifeeding: Allows for a set number of pieces to be pulled from one feeder, then collated, folded and inserted automatically
- Fold Types: C, V, Z, Double Parallel, No Fold
- Full-Page CIS Scanner: Spans the width of the feeders and reads OMR, 1D and 2D BCR codes printed horizontally or vertically anywhere on the page, without the need for physical adjustments
- Fold Only without Inserting
- Daily Mail Mode: For inserting stapled sets
- Seal and Non-Seal Capabilities
- Cascade Mode: Maximizes output by connecting multiple feeders with the same document. When one feeder empties, the next automatically starts feeding, for a total hopper capacity of up to 975 sheets.
- Enhanced Folding System: Fold/insert up to 8 pages in tri-fold and up to 10 pages in half-fold
Options:
- Production Feeder: High capacity feeding of inserts up to 6” long, or up to 14” long with optional license
- Short Feed Trays: For feeding BREs and short inserts
- Advanced OMR, Advanced BCR, MailDoc: Designed for the most secure intelligent mail processing
- Side Exit Tray: Holds up to 400 envelopes
Videos
Formax FD 6308 Office Inserter Demo Video
Transcript:
Formax presents the 6308 Series Inserters. Formax 6308 Series Inserters are compact, easy-to-use, and energy-efficient. Ideal for adapting to a variety of office mailing needs. These inserters can process up to 40,000 mail pieces per month at speeds of up to 3,800 per hour, saving both time and money. A seven-inch color touch screen, automatic job setup, and 50 programmable jobs make operation easier than ever before. The superior clamshell cover design provides users with easy access to make ad...
Read More
Formax presents the 6308 Series Inserters. Formax 6308 Series Inserters are compact, easy-to-use, and energy-efficient. Ideal for adapting to a variety of office mailing needs. These inserters can process up to 40,000 mail pieces per month at speeds of up to 3,800 per hour, saving both time and money. A seven-inch color touch screen, automatic job setup, and 50 programmable jobs make operation easier than ever before. The superior clamshell cover design provides users with easy access to make adjustments and clear the paper path. The 6308 also features a convenient shelf for mail preparation and a paper path window, which allows users to see the insert area while in operation.For energy savings; the 6308 Series includes an automatic sleep mode, which puts the inserter into standby after one hour of being idle. A high-capacity vertical output stacker holds up to 500 sealed or unsealed finished pieces in a neat, sequential stack, making them easy to unload for further processing. The user-friendly colored touchscreen control panel features a graphic user interface with paper and envelope presence sensors to indicate when a feeder is empty. In addition, models can be configured with an Intelligent Mark CIS scanner for seamless and secure processing of multi-page documents, including invoices or statements.Three feeder styles are available for optimal performance: the standard-size feeder holds up to 325 sheets, the high-capacity feeder holds up to 725 sheets, and the optional production feeder holds up to 1,200 inserts or 325 business reply envelopes. The 6308 Series comes in four different configurations to meet various mailing requirements. Visit www.Formax.com to learn more about the 6308 Series Inserters and other Formax solutions.The 6308 Series comes in four configurations, available with or without intelligence, including:A three-station configuration with three standard feeders.
A three-station configuration with a combination of standard and special feeders.
A two-station configuration with one standard feeder and one high-capacity document feeder.
A two-station configuration with one special feeder and one high-capacity document feeder.
Operating the 6308 is simple and intuitive. Begin by loading the feeders. The standard size feeders can be linked for a total capacity of up to 975 sheets. Next, load the envelope feeder with up to 350 envelopes. The bottom feed system allows for envelopes to be loaded on the fly for continuous operation. With the feeders loaded, choose either automatic or the step-by-step job wizard to set up the mailing. The automatic setting will detect the document and envelope sizes and automatically fold and insert the mail pieces based on this information. Press the 1X button for a test piece. Check the piece to be sure it's correct. If the documents are accurately folded and inserted, press the Mail OK button, then press the Start button to begin processing. The job can be saved into memory for future use. Formax 6308 Series Inserters combine user-friendly features with high productivity and are ideal solutions for a growing office environment.
