Formax FD 3302 Air-Suction Document Folder
10095 NewCondition InStock

Formax FD 3302 Air-Suction Document Folder

Item #: 04FXFD3302
Brand: Formax
  • Air suction technology
  • Extended infeed tray
  • Handles sheets up to 25.5" L
  • Folds up to 18,600/hour
  • 85+ Years Experience
  • Free Shipping $75+
  • Brand New

$10,095.00

SWIPE FOR MORE IMAGES
  • 0
  • 1
  • 2
  • 3
  • 4

Overview

Finish prints on-demand with FD 3302 Air-Suction Document Folder. This compact and fully automated tabletop machine is ideal for giving digitally printed documents on heavy and coated stock a professional finish. The folder features an air-suction feed technology that minimizes static electricity and significantly lessens feed marks commonly encountered in traditional friction feed systems. Internal fans produce air and suction for quiet operation while a side air system enhances the feeding of heavier stocks and larger sheets.

Specifications

Item #04FXFD3302
ManufacturerJames Burn
Manufacturer Item #04FXFD3302
SpeedUp to 18,600 sheets/hour (11”, single fold) Five speed levels
Hopper CapacityUp to 1.96” high, 625 sheets (64gsm)
Pre-Set FoldsC, Z, Half, Fold Out, Gate, Double Parallel, Custom, Cross Fold created by feeding through a second time
Custom FoldsUp to 30
Paper Size4.73” x 7.2” up to 12.2” x 25.5”
Paper WeightUncoated
Coated73.3 - 157gsm (19 - 40#)
MaximumUp to 230gsm (single fold) [Maximum paper weight 230gsm with limitations. Testing is required.]
Feed TypeAir suction belt
Double Feed DetectionOptical and ultrasonic sensors
Dimensions53.3" L x 23.2" D x 24.2" H
Weight157 lbs
Power110-240V, 50/60 Hz

Description

Finish prints on-demand with FD 3302 Air-Suction Document Folder. This compact and fully automated tabletop machine is ideal for giving digitally printed documents on heavy and coated stock a professional finish. The folder features an air-suction feed technology that minimizes static electricity and significantly lessens feed marks commonly encountered in traditional friction feed systems. Internal fans produce air and suction for quiet operation while a side air system enhances the feeding of heavier stocks and larger sheets. The folder works fast at speeds of o 18,600 sheets per hour. The feed tray can hold up to 625 sheets for efficient operation. These capacities and features make the machine suitable for a range of applications. The variable fan speed and airflow can be adjusted independently using the interactive control panel and external adjustment knobs. Other advanced features include an automatic paper size detection and fold plate settings, a 4.3” color touchscreen LCD control panel, six programmed fold settings, and the ability to store up to 30 custom folds. It also includes a cross folding guide, a four-digit counter with batch counting capability, four fold rollers for accuracy, and document security features.

  • Operating Features:
    • Air-Suction Feed System: Designed to easily handle static buildup in digital prints and minimize feed marks
    • 4.3” LCD Color Touchscreen Control Panel: User friendly, with energy-saving mode
    • Extended Infeed: Accommodates sheets up to 25.5” long
    • Automatic Paper Size Detection: Recognizes the most popular paper sizes including letter, legal, ledger, half letter and half legal
    • Side Air System: External fan enhances feeding of heavy stock and large paper sizes
    • Adjustable Air Flow: Allows for feeding consistency of varying paper weights / sizes
    • Double Feed Detection: Optical and ultrasonic sensors ensure document integrity
    • Outfeed Stacking Belt & Rollers: Automatically adjust to paper size for optimal stacking
    • Batch Counting: Programmable to process pre-set number of sheets into sets with a delay between sets
    • Idling Function: Standby mode used to pause for double or misfeed. All other functions are still operational, minus the output drive.
  • Folding Features:
    • Pre-Programmed with 6 Standard Folds: C, Z, Half, Fold Out, Gate and Double Parallel
    • Custom Folds: Up to 30 custom folds can be programmed and stored into memory
    • Cross-Folding: A guide is included for two-pass operation
  • Technical Features:
    • Noise Reduction: Fold plates are enclosed and insulated to reduce operating noise
    • Built-in DC Fans: Provide quieter operation than external pumps
    • Seven-Point Fold Stops: Fold plates utilize seven point fold stops for crisp, accurate folds of large paper sizes at high speeds
    • Four-Digit Counter: Includes addition, batch and interval counting
    • Adjustable Stack Height Lever: Five positions can be easily chosen to increase or decrease paper stack height to better feed thick and thin paper stocks
    • Four Fold Rollers: Produce crisp, precise folds
    • Fault Detection Features: Paper Out, Misfeed, Double Feed, Paper Jam, Top Cover Open, Paper Size Error
    • Easy Access to Paper Path: Easily clear paper jams
  • Options:
    • 402 Series Air Jogger: Reduces static electricity and aligns forms for proper feeding
