James Burn Onglematic O7 Tab Cutter w/ 1/2 Ext. Double Round Corner
23291.9
NewCondition
InStock
James Burn Onglematic O7 Tab Cutter w/ 1/2 Ext. Double Round Corner
SWIPE FOR MORE IMAGES
- 0
- 1
- 2
- 3
- 4
- 5
- 6
- 7
- 8
- 9
- 10
Overview
The Onglematic O7 is a versatile table top electric tab index & divider cutter for bound documents or loose leafs designed for mid-size to intensive production volume requirements. It is able to produce 60 bound documents of 10 chapters with about 150 sheets (80gsm) or 550 sets of 9 dividers (220gsm sheets) per hour.
Specifications
Item # | 04JBO7DRTABCU |
---|---|
Manufacturer | James Burn |
Manufacturer Part Number | 04JBO7DRTABCU |
Cutting Width | 320mm / 12.5" |
Cutting Thickness | Up to 35 – 40 sheets (80gsm) |
Number of tabs | 2 |
Voltage | 120/240V- 1ph |
Machine Dimensions | 0 x 57 x 42 cm (H/a) |
Machine Weight | 132 lbs |
Description
The Onglematic O7 is a versatile table top electric tab index & divider cutter for bound documents or loose leafs designed for mid-size to intensive production volume requirements. It is able to produce 60 bound documents of 10 chapters with about 150 sheets (80gsm) or 550 sets of 9 dividers (220gsm sheets) per hour.
Features:
- Versatility at its best: The Onglematic 7 excels in creating single or double tabs, effortlessly slicing through 15-20 sheets of 20 lb. bond paper. Not limited to paper, it adeptly handles cover stock, cardboard, and poly up to 120 lb. Achieve up to 59 tabs with the same width or cut up to 24 tabs with varying width, with storage for up to 11 programs.
- Efficiency in action: Experience top-notch efficiency as the Onglematic 7 churns out 60 bound documents with 10 chapters, featuring around 150 sheets (80 lb. cover) or 550 sets of 9 dividers (20 lb. cover) per hour.
- User-friendly operation: Enjoy the simplicity of on-demand tab cutting with automatic operation. Set the cutter to your paper size (in inches or mm), choose between single or double tabs, and specify the desired tab quantity. Activate the foot switch to cut the first edge and repeat for the entire set.
- Ergonomic brilliance: All operations unfold seamlessly from the front of the machine, with the added convenience of foot switch activation.
- Diverse tab options: Select from five tab shapes, including standard, 15° angle, 90° angle, 90° angle with internal round corner, and 90° angle with double round corner, each featuring a ½" tab extension.
- Safety paramount: The Onglematic 7 prioritizes safety with built-in features ensuring secure operations.
- Automatic cut by foot switch activation.
- Automatic or manual advance after each cut.
- Digital adjustment : the stop moves automatically from one position to the next one upon validation by the operator.
- Variable tab lengths with storage of up to 64 programmes.
- Bound document clamping device.
