Overview
Formax’s Cut-True 28A prioritizes safety and precision making it a great addition to your workflow. This automatic paper cutter can handle paper stacks up to 18.9” wide and 3.15” tall. The steel blade and digital adjustment system will give you a perfect clean cut every time.
Specifications
| Item # | 04FXFCT28A |
|---|---|
| Manufacturer | Formax |
| Manufacturer Part Number | Cut-True 28A |
| Brand Name | Formax |
| Cutting Action | Dual-button electric |
| Compatible Supplies & Accessories | 27-10 Replacement Blade 27-20 Replacement Cutting Sticks (8 pack) |
| Maximum Cutting Width | 18.9” (480mm) |
| Maximum Paper Stack Height | 3.15” (80mm) |
| Cutting Length Behind Blade | 18.9” (480mm) |
| Table Size in Front of Blade | 32” W x 37” D (811 x 941mm) |
| Narrow Cut | 1.37” (35mm) |
| LED Cutting Line | Yes |
| Clamp Style | Automatic |
| Back Gauge Adjustment | Touchscreen or electronic hand wheel |
| Back Gauge Reading | Color touchscreen, in both standard and metric |
| Programmable Jobs | Up to 99, with up to 30 cuts |
| Blade Change Safety Tool | Included |
| Dimensions | 60” H x 36” W x 40” D (1520 H x 920 W x 1010mm D) |
| Weight | 575 lbs (260kg) |
| Power Supply | 110V, 20A dedicated line |
| Safety Certifications | UL approved |
Description
The Formax Cut-True 28A is a great way to upgrade your print shop and in-house finishing operations. This automatic paper-cutting machine allows for bulk cutting of stacks up to 18.9” wide and 3.15” tall. Its hardened steel blade can cut cleanly through every load with ease and precision. The LED visual line along with digital fine adjustment knobs allows you to align and position your blade perfectly. For repeat jobs, program up to 99 jobs with 30 cuts each for an exact result every time. The stack paper cutter offers standard blade safety features as well as an infrared safety curtain that shuts down operation the moment the light plane is broken.
For ultimate productivity and safety, the Formax Cut-True 28A can transform how you cut paper.
Features:
- Fully automatic and customizable with programmable settings.
- Easy-to-use touchscreen control panel.
- Safety first with electronically-controlled two-hand operation.
- Fine-tune the back gauge electronically for precision every time.
- Equipped with a high-speed, hardened steel blade for smooth cutting.
- Features an automatic geared clamping system for secure and efficient operation.
- Blade automatically returns to its original position, no matter where you stop.
- Built tough with a solid steel blade carrier.
- Comes with a main switch and safety lock, complete with a key for extra security.
- Includes a wooden paper pusher to help you align everything perfectly.
- Blade change? No worries—it comes with a safety tool just for that.
- Sturdy all-metal stand with a built-in storage shelf to keep everything neat and tidy.
- Supplies:
- Replacement Blade - 27-10
- Replacement Cutting Sticks - 27-20 (pkg of 8)
Videos
Cut-True 28A Automatic Guillotine Cutter
The Formax Cut-True 28A automatic guillotine cutter provides precision paper cutting for seats up to 18.9 inches wide, ideal for on demand print shops and implant centers. The 28A features programmable job settings, an infrared light beam safety curtain, hardened steel blade, and a large color touchscreen control panel for quick and easy setup and operation. The Cut-True 28A quickly and accurately cut stacks up to 3 inches high. The bright LED cutting line indicates exactly where the blade will cut, allowing operators to make fine adjustments. Two button operation engages the clamp and hardened steel blade for crisp, accurate cuts every time. The user-friendly touch screen control panel allows operators to program up to 99 jobs with up to 30 cuts each. When using cut through cutters, safety is the top priority, the infrared light beam curtain provides both safety and convenience as it shuts down operation if the light plane is interrupted. A key lock, wooden paper push, tool kit, and blade change tool are also standard features for safe operation. In addition, the Cut-True 28A comes standard with a rugged metal stand and an integrated shell for convenient storage.
Let's take a look at a basic cutting job to begin select or set the program using the control panel, which will automatically adjust the back gauge. Next, slide the paper stack into position and use the wooden paper push to safely align the stack. Notice how the bright LED laser line shows exactly where the blade will cut. To make slight back gage adjustments, the fine-tuned dial can be used for precision cutting. With the paper in position, press the two activation buttons to engage the cutting blade while keeping hands away from the cutting area. The hardened steel blade is designed to last, cut after cut. When it does need to be replaced, the blade change tool makes it safe and easy. Cutting sticks are also safe and easy to replace. Simply press the lifting button located on the cutting deck and the stick will be raised for easy removal. The Cut-True 28A electric cutter is ideal for transforming on demand, digitally printed sheets into brochures, invitations. and more. Combining accuracy with safety. It's a welcome addition to on demand, print shops, and in plant finishing operations.
