Formax Atlas-AS Air Feed Document Folder
18195
NewCondition
InStock
Formax Atlas-AS Air Feed Document Folder
SWIPE FOR MORE IMAGES
- 0
- 1
- 2
- 3
- 4
- 5
Overview
The Formax ATLAS-AS Air-Feed Document Folder combines high-volume output with user-friendly features in a rugged, small footprint. With variable speed control, it can process up to 27,500 sheets per hour. Its 7" full-color touchscreen control panel allows operators to set up jobs easily and to program an unlimited number of jobs into memory. The fold rollers are made of a durable composite material designed to easily grip high-gloss paper, and are housed in a single patented pull-out cassette.
Specifications
| Item # | 04FXATLASAS |
|---|---|
| Manufacturer | Formax |
| Manufacturer Part Number | ATLAS AS |
| Brand Name | Formax |
| Operation | Electric |
| Compatible Supplies & Accessories | AF-05 Narrow Sheet Guide Attachment AF-10 56-Tooth Perforating Wheel AF-15 Peforating Anvil AF-20 Light Scoring Wheel AF-30 Heavy Scoring Wheel AF-25 Scoring Anvil AF-35 Additional Perforating / Scoring Wheel Assembly FD 402TA1 / FD 404A1 Air Joggers |
| Power Voltage | 220V, 60Hz, 30 Amp |
| Speed | Up to 27,500 per hour |
| Dimensions | 48.8" L x 21.8" D x 54" H |
| Manufacturer's Warranty | 90 Day Warranty |
| Fold Types | Letter Fold, Half Fold, Z-Fold, Double Parallel Fold, Gate Fold, Zig-Zag Fold, Fold-Out Fold |
| Minimum Sheet Size | 6.2” L x 5.5” W |
| Maximum Sheet Size | 26.5” L x 14.3” W |
| Paper Weight | Min: 16# bond / Max: 90# cover |
| Product Weight (lbs) | 265 |
| Shipping Weight (lbs) | 267 |
Description
The Formax ATLAS-AS Air-Feed Document Folder combines high-volume output with user-friendly features in a rugged, small footprint. With variable speed control, it can process up to 27,500 sheets per hour. Its 7" full-color touchscreen control panel allows operators to set up jobs easily and to program an unlimited number of jobs into memory. The fold rollers are made of a durable composite material designed to easily grip high-gloss paper, and are housed in a single patented pull-out cassette.
The powerful air suction feed table of the Atlas -AS handles a wide variety of coated or non-coated stock, up to 26.5" in length, and aligns the sheets prior to folding. It also features a suction chamber to control curled or statically charged paper. Standard features include a modular perforator/scorer which can also be used as a roller bypass, allowing cover stock to be folded and output flat. The outfeed stacker features rollers which adjust automatically, and is located on the same side as the infeed, allowing operators to easily operate the Atlas-AS from a single position. Double document and jam detection, batch counting, anti-static brushes, skew and micro adjustments complete the user-friendly package.
Features:
- High-Speed Output: Large jobs are processed quickly at speeds of up to 27,000 pieces per hour
- Powerful Air Suction Feed Table: Handles a variety of coated and non-coated stock, in a range of paper weights and sizes, up to 26.5" in length
- 7" Color Touchscreen Control Panel: Program and make adjustments quickly and easily with graphics-based menus
- Low-Pressure Air Chamber: Specially designed to control curled paper prior to entering fold rollers
- Simple, Accurate Alignment : Squares and aligns sheets prior to feeding
- BatchCounter: Programmable to process pre-set number of sheets into sets with a delay
- Six Standard Folds in Common Paper Sizes: Pre-programmed for 6 popular fold types in letter, legal and ledger paper sizes equalling 18 preset fold settings
- Unlimited Custom Folds: Program and store an unlimited number of custom folds into memory
- Fully-enclosed Fold Plates: Sound reduction
- Easy-to-Use Fold Settings: Set and adjust folds using the 7" color touchscreen control panel
- Durable Fold Rollers: Made of composite material designed to easily grip high-gloss paper, and are housed in a single patented pull-out cassette
- Belt-Driven Outfeed Stacker: Located on the same side as the infeed table, allows operators to easily load and unload the Atlas from a single position
- Compact, Rugged Unit: High-volume, high-speed output in a small footprint
- Perforating / Scoring: Easy-to-use plug-in perforator / scorer delivers finished pieces to a catch tray, and can also be used as a roller bypass, allowing cover stock to be folded and delivered flat
- Anti-Static Brushes: Improves paper feeding
- Skew and Micro Adjustments: Allow for fine tuning and crisp, precise folds
- Double Document Detector: Detects and helps to prevent paper jams caused by double feeding
Available Options:
- Narrow Sheet Guide Attachment: Makes feeding narrow sheets quick, easy and accurate
- 56-Tooth Perforating Wheel: Used to perforate paper and card stock
- Perforating Anvil: Used in conjunction with 56-Tooth Perforating Wheel
- Light Scoring Wheel: Provides light scoring on most paper stocks
- Heavy Scoring Wheel: Provides heavy scoring on thicker paper stocks
- Scoring Anvil: Used in conjunction with AF-20 and/or AF-30 Scoring Wheels
- Additional Perforating / Scoring Wheel Assembly
Videos
Formax Atlas-As Air-Feed Folder Demo Video
Transcript:
Formax presents the Atlas AS air feed folder. The Atlas AS is a powerful, compact air feed folder that meets the quality demands of light production folding. Easy setup and user-friendly operations separate this folder from the rest. The Atlas AS features a powerful air suction feed table with an alignment deck for consistent, accurate feeding of forms, an innovative fold roller access design, and a perforator/score attachment. Let's take a closer look at how the Atlas AS works.Step one: To set ...
Read More
Formax presents the Atlas AS air feed folder. The Atlas AS is a powerful, compact air feed folder that meets the quality demands of light production folding. Easy setup and user-friendly operations separate this folder from the rest. The Atlas AS features a powerful air suction feed table with an alignment deck for consistent, accurate feeding of forms, an innovative fold roller access design, and a perforator/score attachment. Let's take a closer look at how the Atlas AS works.Step one: To set the infeed gap, take two sheets of paper and slide them under the bow nose, then lower the bow nose until there is a slight drag when pulling the paper back.
Step two: Adjust the side guides for the paper size being used. Loosen the knobs and slide the guide wall in or out, leaving about a 16th of an inch gap between the paper and the wall, then tighten into position.
Step three: Slide the rear guide into position so it's snug against the end of the paper stack.
Step four: Adjust the side air so that the paper elevates and reduces friction. Three settings can be selected based on the paper length and thickness. And Step 5: Adjust the suction that will pull the paper in, more for heavy stock and less for lighter stock.
With the in-feed adjusted, the fold plate can be set to fold type and paper length. The Atlas AS is pre-programmed with 6 popular fold types in 3 different sizes. In addition, an unlimited number of custom jobs can be stored. With the in-feed table set, simply select the desired fold type and paper size using a full-colored touch screen. The fold plates and out-feed stacker wheels will adjust automatically. All-metal sturdy construction of the Atlas AS fold plates provides consistent folds, and these are well-insulated for noise reduction. To access the fold rollers for routine maintenance or cleaning, remove the fold plates, then loosen and remove the thumb screws on either side of the folder. Then simply slide the fold roller compartment up and out of the folder for complete access. It is just as easy to slide back to its position.
The Atlas AS comes standard with a perforator/score attachment which is conveniently stored below the lower fold plate. Installation is easy with no tools required. It simply takes the place of the lower fold plate. Remove the fold plate to access the attachment and catch tray. First, install the catch tray; now install the perforator/scorer. The blades can be adjusted for different paper widths and can be swapped out to perforate/scorer. With the perforator scorer in place, load your paper and press start. Paper is folded and perforated as shown here or it can just be perforated/scored. In addition, the perforator/score attachment can be disengaged which allows heavier weight paper to be folded and laid flat without curling. The Formax Atlas AS air feed folder is easy to set up and operate, with the power, durability, and consistency needed for a light production environment in a rugged compact design.
