HIX B-250D Hat Press

Item #: 04HIXB250D

The HIX B-250D is a portable hat press that features a transfer hold down blanket to prevent transfer shifting. It is a manual cap press that comes with a standard 3-7/8"x 5-7/8" heat platen.

Qty/Pack : 1

Product Description


The HIX B-250D is very portable making it easy to take to shows and operate. The transfer hold down blanket means transfers don't shift anymore. With a standard heat platen of 3-7/8"x 5-7/8", place transfers easily onto hats.

The B-250D cap press is a manual machine with a 3-7/8" x 5-7/8" heat platen. It features a digital timer (optional analog) that is adjustable up to 999 seconds and shows countdown on readout; then beeps after elapsed time and resets when the easy to open and close handle (with full range pressure adjustment) is raised. The calibrated digital temperature control is adjustable up to 450°F (232°C) and displays the current temperature.

The innovative bottom cap hold-down stretches the cap out holding it snug to the lower (rubber covered) platen. A PTFE blanket is suspended between the upper and lower platen to hold the transfer (or lettering) in place before the heating element is locked down.

The B-250D comes standard with a Golf size (3"x5-1/2") lower, rubber covered platen. It can be interchanged with the optional Youth size (2-3/4"x5-1/4") or Ball size (3-3/4"x5-7/8"). HIX can make custom platens as well.

All HIX Corporation heat presses have been made in the USA since 1963 and are "Certified Green", meaning that all HIX heat press machines:

  • Use 43% less electricity
  • Let off less radiant heat
  • Provide cooler work areas
  • Create lower energy bills for a lower overall cost


Item # 04HIXB250D
Manufacturer HIX Corporation
Model B-250D
Operating Method Manual
Included Supplies & Accessories PTFE Blanket, Golf Size Heat Platen [3" x 5-1/2"]
Power Voltage 120 V
Certifications CE, ETL, UL, CSA
Manufacturer's Warranty 1 Year (Parts), Lifetime (Heating Element)
Quantity 1
Compatible Supplies & Accessories Interchangeable Lower Platen: HIX Youth Size (2-3/4" x 5-1/4"), HIX Ball Size (3-3/4" x 5-7/8"), Custom HIX Heat Platens
Heat Press Type Hat Press
Platen Size 3" x 5 ½" Platen
3 ⅞" x 5 ⅞" Lower Rubber Coated Platen
3 ⅞" x 7" Heat Head
Adjustable Pressure Full Range Pressure Adjustment
Temp Control Adjustable to 450°F (232°C)
Temperature Read Accuracy Displays Current Temperature
Heat Press Timer Digital Timer (Adjustable up to 99 Minutes, 59 Seconds)
Heat Transfer Applications Caps, Hats, Bandannas, Pockets, Collars & More
Product Weight (lbs) 24
Shipping Weight (lbs) 31
Shipping Information Shipping Dimensions: 19" x 16" x 19"
